The 1S module is suitable for a single LiPo/LiIon cell or a multi-cell NiMH battery. The other connectors will have cell count + 1 pins.Ī PPTC resettable fuse in the battery positive leadĪ small on/off switch and charge socket module for model vehicle installation. The JST-RCY connector is only appropriate for the 1S switch.
NiMH batteries need only a 2 wire charge connector so select 1S for these.Īn adapter lead will be needed to connect the switch module to your charger: NiMH or 1S:Ī tiny on/off slide switch and charge socket module for model vehicle installation, comprising micro slide switch 2mm pin space Molex charge connector and 1.8mm LED mounted on a 20mm x 10mm GRP plate. Lithium batteries (LiPo or LiIon) require one more charge wire than the number of cells so you must select the correct 'S' count for your battery. The switch modules may be used for any battery type. The GRP plate is supplied without any mounting holes as it may be either glued into place or holes made and fixed with small (e.g.
#5 PIN MOLEX CONNECTOR PLUS#
They comprise a small GRP plate containing a slide or toggle switch plus a Molex 2mm pitch plug (male plastic shell, female metal parts) and an LED which may be used to monitor the receiver status. These switch/charge modules provide a simple way to implement an on/off switch and charge connector on your model vehicle. ( Top | Plugs/Sockets | Leads | Adapter Leads) ( Top | Leads | Adapter Leads | Switch Modules)Ī 5 pack of Molex 2mm pitch plug shells and crimp terminals (each packet contains 5 spare crimps for you to practice). All leads and LiPo supplied by Micron are wired this way - see Connector Wiring for details please contact us if you need your LiPo or Molex 2mm leads wired with pin 1 positive. The Micron convention is that negative is at position 1, as shown in the image of a socket at the right. Unfortunately, there is no manufacturer consistency in the way that the negative and positive wires are inserted into the shell. Many single and 2S LiPo come fitted with a 2 pin plug. The 2 pin versions provide a very small but safe method of connecting and disconnecting LiPo and the 3, 4 and 5 pin versions can be used for balance connections where a JST-XH would take up too much space.Ī plug is a male plastic shell with female crimp terminals and a socket is a female plastic shell with male crimp terminals. These 2mm pitch plugs and sockets are ideal for use in limited spaces. JST-SH | Molex Picoblade (1.25mm) | JST-ZH | JST-PH | JST-RCY | 1.27mm | AR6400/PKZ3352 | DC | Power Most devices on the market are compatible with this standard.About shipping charges and VAT if your delivery address is outside the U.K. USB 2.0 allows for a transfer speed of 480 Mbps. The USB version relates to the technology that allows the data to be transferred along a cable from one device to another. This Mini B socket connector is compatible with both the USB Type 2.0 Mini B and AB plug.
#5 PIN MOLEX CONNECTOR PC#
